MuShield offers a Magnetic Shield Sample and Design Kit:

Are you trying to decide which magnetic shielding material is right for you? Do you want to experiment with high, medium and low permeability magnetic shielding alloys and thicknesses?

If you said, “yes” to either of the questions above, MuShield’s Magnetic Shielding Sample and Design Kit may be right for you!

MuShield offers a Magnetic Shielding Sample and Design Kit created specifically for engineers looking for a quick and inexpensive way to solve their magnetic interference problem either in the R & D or production phases.Each MuShield Magnetic Shielding Sample and Design Kit contains a selection of technical features related to working with high, medium, and low permeability magnetic shielding materials, design considerations for your magnetic shield, and selection of magnetic shielding materials including mumetal and Alloy 49

In this kit you will find resources to  help design and build your own magnetic shield. This kit is the first step to solving your magnetic interference problem. Read the information given in this pamphlet and start working with the materials to gauge what type of magnetic shield would best suits your specific need. After reviewing the technical data, start working with the various types of materials found in this kit.

Specific Materials Found Within the Kit: Note that all materials are in the mill annealed condition. Subsequent heat treating is needed to restore the material to its maximum magnetic permeability

The MuShield Magnetic Shield Sample and Design Kit ($195)

mumetal High Permeability Foil- 1 of each
Material per ASTM A753 Alloy Type 4 and MIL-N-14411 Composition 1

  • .004″ x 15″ x 12″
  • .006″ x 15″ x 12″
  • .010″ x 15″ x 12″

mumetal High Permeability Sheet- 1 of each
Material per ASTM A753 Alloy Type 4 and MIL-N-14411 Composition 1

  • .020″ x 6″ x 8″
  • .040″ x 6″ x 8″
  • .060″ x 6″ x 8″

Alloy 49 Medium Permeability Sheet- 1 of each
Material per ASTM A753 Alloy Type 2 and MIL-N-14411 Composition 3

  • .020″ x 6″ x 8″
  • .040″ x 6″ x 8″

MuShield Low Permeability (High Saturation) Silicon Iron Sheet- 1 of each

  • .007″ x 14.5″ x 12″

Laminated Adhesive Double Sided

  • 2 Square ft

Technical Details Found in the Kit

  • “How Magnetic Shielding Works”
  • “Designing a Magnetic Shield”
  • “The Math Behind Magnetic Shielding: Selecting the Proper Thickness”
  • “Selecting Magnetic Shielding Materials: High, Medium and Low Permeability”
  • “Prototyping With High Permeability Magnetic Shielding”
  • “Heat Treating Magnetic Shielding Materials”
  • “Heat Treating vs. Annealing”
  • “Hydroforming and its Value to Magnetic Shielding”
  • “Magnetic Shielding Materials”

Order Now
